Product Description
THE MAIN USE IS THE MAIN USE OF THE MARIN APPLICATION
This Best customized industrial pulverizer machine product is suitable for material crushing in chemical, pharmaceutical, food, and other industries.
MAIN FEATURES CHARACTERISTICS
The crushing chamber can adopt a turbine, blade, hammer, and other crushing structures, which adopt inline discharge to reduce the phenomenon of small production volume and high temperature caused by wind resistance. The machine has a buffer buffer-discharging device and an automatic separation effect between material and air pressure. The machine is a new generation of ideal shredding equipment for high output.
HOW IT WORKS PRINCIPLE
This Best customized industrial pulverizer machine products use the relative movement between the movable toothed disc and the fixed toothed disc to crush the crushed object through tooth impact, friction, and material impact between each other. The whole machine is designed according to the "GMP" standard, all made of stainless steel materials, the machine has a simple structure, high output, is easy to clean, and is the ideal crushing equipment at present.
TECHNICAL PARAMETERS
| Model | Production Capacity | Feeding Size | Output Size | Total Power | Main speed | Overall Dimension(L*W*H) | Weight |
| WF-15 | 10-200kg/h | ＜10mm | 80-320 | 4kw | -6000r/min | 1000*1000*1600（mm） | 850kg |
| WF-30 | 30-800kg/h | ＜15mm | 80-320 | 5kw | -3800r/min | 1000*1000*1600（mm） | 1500kg |
| WF-60 | 50-1200kg/h | ＜15mm | 80-300 | 11kw | -2800r/min | 1000*1000*1600（mm） | 3200kg |
| WF-80 | 100-1500kg/h | ＜15mm | 80-300 | 22kw | -2500r/min | 1000*1000*1600（mm） | 3700kg |
WF-C type pulverizer series
THE MAIN USE IS THE MAIN USE OF THE MARIN APPLICATION This machine is suitable for material crushing in chemical, pharmaceutical, food and other industries.
Get in touch for more information or to arrange a demo:
Products Category
Product Description
THE MAIN USE IS THE MAIN USE OF THE MARIN APPLICATION
This Best customized industrial pulverizer machine product is suitable for material crushing in chemical, pharmaceutical, food, and other industries.
MAIN FEATURES CHARACTERISTICS
The crushing chamber can adopt a turbine, blade, hammer, and other crushing structures, which adopt inline discharge to reduce the phenomenon of small production volume and high temperature caused by wind resistance. The machine has a buffer buffer-discharging device and an automatic separation effect between material and air pressure. The machine is a new generation of ideal shredding equipment for high output.
HOW IT WORKS PRINCIPLE
This Best customized industrial pulverizer machine products use the relative movement between the movable toothed disc and the fixed toothed disc to crush the crushed object through tooth impact, friction, and material impact between each other. The whole machine is designed according to the "GMP" standard, all made of stainless steel materials, the machine has a simple structure, high output, is easy to clean, and is the ideal crushing equipment at present.
TECHNICAL PARAMETERS
| Model | Production Capacity | Feeding Size | Output Size | Total Power | Main speed | Overall Dimension(L*W*H) | Weight |
| WF-15 | 10-200kg/h | ＜10mm | 80-320 | 4kw | -6000r/min | 1000*1000*1600（mm） | 850kg |
| WF-30 | 30-800kg/h | ＜15mm | 80-320 | 5kw | -3800r/min | 1000*1000*1600（mm） | 1500kg |
| WF-60 | 50-1200kg/h | ＜15mm | 80-300 | 11kw | -2800r/min | 1000*1000*1600（mm） | 3200kg |
| WF-80 | 100-1500kg/h | ＜15mm | 80-300 | 22kw | -2500r/min | 1000*1000*1600（mm） | 3700kg |
