Product Description
THE MAIN USE IS THE MAIN USE OF THE MARIN APPLICATION
This Best turbo grinder machine in China is mainly suitable for pharmaceutical, chemical, food, pesticide, building materials, and plastics industries, Mohs hardness is less than 3, soft, brittle, and fiber and other materials crushing. Such as medicinal materials, dyes, pigments, food additives, and plastic additives can obtain satisfactory crushing effects.
HOW IT WORKS PRINCIPLE
The main technical feature of the machine is that the dynamic pressure generated by the crushing knife is used to quickly discharge the product out of the machine cavity. The secondary air inlet (optional) can be set to form an air cushion in the inner cavity of the casing to reduce the exhaust air resistance, and it can also be connected to the tail air pipe of the recovery system and can be connected to the automatic or pulse box dust collector, its main function is to avoid dust flying field and reduce the loss of materials, play a role in recycling and reuse, and reduce environmental pollution. Comply with GMP standards. The working principle of this Best turbo grinder machine in china is mainly to crush the impact on the material between the red plate and the activity, and also use the vortex air flow generated by the back of the knife to strengthen the crushing of the material. If the material has low heat sensitivity, it can be equipped with a cold air circulation cooling device (the temperature can be controlled at -20 to -30 degrees) or a cryogenic package, which is used in biopharmaceuticals or frozen crushing.
TECHNICAL PARAMETERS
| Model Model | Type 20 | Type 30 | Type 40 | Type 60 |
| Production capacity (kg/h) | 20-120 | 30-250 | 50-450 | 80-800 |
Spindle speed (r/min) Rotary Speed | 4500 | 4000 | 3500 | 2800 |
Rotor diameter (mm) Dia of Rotor | 200 | 300 | 400 | 600 |
Main engine power (kW) Motor Power | 4 | 7.5 | 11 | 22 |
| Output Fineness | 20-150 | 20-150 | 20-150 | 20-150 |
| Feeding Granularity | ≤6 | ≤6 | ≤10 | ≤10 |
Main engine weight (kg) (does not contain the electrical machinery weight) | 480 | 550 | 730 | 900 |
WF turbogrinder
THE MAIN USE IS THE MAIN USE OF THE MARIN APPLICATION This machine is mainly suitable for pharmaceutical, chemical, food, pesticide, building materials, and plastics industries, Mohs hardness is less than 3, soft, brittle, and fiber and other materials crushing. Such as medicinal materials, dyes, pigments, food additives, and plastic additives can obtain satisfactory crushing effects.
Get in touch for more information or to arrange a demo:
Products Category
Product Description
THE MAIN USE IS THE MAIN USE OF THE MARIN APPLICATION
This Best turbo grinder machine in China is mainly suitable for pharmaceutical, chemical, food, pesticide, building materials, and plastics industries, Mohs hardness is less than 3, soft, brittle, and fiber and other materials crushing. Such as medicinal materials, dyes, pigments, food additives, and plastic additives can obtain satisfactory crushing effects.
HOW IT WORKS PRINCIPLE
The main technical feature of the machine is that the dynamic pressure generated by the crushing knife is used to quickly discharge the product out of the machine cavity. The secondary air inlet (optional) can be set to form an air cushion in the inner cavity of the casing to reduce the exhaust air resistance, and it can also be connected to the tail air pipe of the recovery system and can be connected to the automatic or pulse box dust collector, its main function is to avoid dust flying field and reduce the loss of materials, play a role in recycling and reuse, and reduce environmental pollution. Comply with GMP standards. The working principle of this Best turbo grinder machine in china is mainly to crush the impact on the material between the red plate and the activity, and also use the vortex air flow generated by the back of the knife to strengthen the crushing of the material. If the material has low heat sensitivity, it can be equipped with a cold air circulation cooling device (the temperature can be controlled at -20 to -30 degrees) or a cryogenic package, which is used in biopharmaceuticals or frozen crushing.
TECHNICAL PARAMETERS
| Model Model | Type 20 | Type 30 | Type 40 | Type 60 |
| Production capacity (kg/h) | 20-120 | 30-250 | 50-450 | 80-800 |
Spindle speed (r/min) Rotary Speed | 4500 | 4000 | 3500 | 2800 |
Rotor diameter (mm) Dia of Rotor | 200 | 300 | 400 | 600 |
Main engine power (kW) Motor Power | 4 | 7.5 | 11 | 22 |
| Output Fineness | 20-150 | 20-150 | 20-150 | 20-150 |
| Feeding Granularity | ≤6 | ≤6 | ≤10 | ≤10 |
Main engine weight (kg) (does not contain the electrical machinery weight) | 480 | 550 | 730 | 900 |
